| 型號 Model/項目 Item | HLS60 | HLS90 | HLS120 | HLS150 | HLS180 | HLS200 | |
|
整機 Whole machine |
理論生產率（m³/h） Theoretical productivity |
60 | 90 | 120 | 150 | 180 | 200 |
|
控制方式 Control mode |
微機 Computer | ||||||
|
計量方式 Weighing mode |
電子稱 Electrical scale | ||||||
|
出料高度（m） Discharging height |
3.8 | ||||||
|
整機裝機容量（kw） Whole machinery capacity |
140 | 165 | 200 | 240 | 255 | 370 | |
|
攪拌機 Mixer |
攪拌機型號 Model of mixer |
MT1500/1000 | MT2250/1500 | MAO3000/2000 | MAO4500/3000 | MAO4500/3000 | MAO6000/4000 |
|
攪拌機功率（kw） Mixing power |
18.5×2 | 30×2 | 37×2 | 55×2 | 55×2 | 75×2 | |
|
入料容積（L） Charging volume |
1600 | 2500 | 3200 | 4600 | 4600 | 6500 | |
|
出料容積（L） Discharging volume |
1000 | 1500 | 2000 | 3000 | 3000 | 4000 | |
|
粒徑碎石/卵石（mm） Diameter of macadam/pebble |
40~80 | 40~80 | 40~100 | 40~100 | 40~100 | 40~100 | |
|
骨料儲系統 |
|||||||
|
配料秤型號 Batcher scale model |
DPL2400A | DPL2400B | DPL3200 | DPL4800A | DPL4800 | DPL6400 | |
|
配料種類 Types of ingredients |
3Piece(種) | 3~4Piece(種) | 4Piece(種) | 4Piece(種) | 4Piece(種) | 4Piece(種) | |
|
砂石儲料倉容積（m³） Aggregate storage hopper volume |
8×3 | 15×3~4 | 20×4 | 25×4 | 25×4 | 地倉 | |
|
計量范圍及精度 Weighing range & accuracy |
200~3000±2% | 1800×3~ 3±2% | 2200×4~±2% | 3500×4~±2% | 3500×4~±2% | 4800×4~±2% | |
| 水平皮帶機輸送能力（t/h）Horizontal belt conveyor capacity | 280 | 480 | 480 | 800 | 800 | 1000 | |
|
粉料儲供系統 Powder storage system |
傾角皮帶機輸送能力（t/h） Slant belt conveyor capacity |
350 | 600 | 600 | 1000 | 1000 | 1100 |
|
粉料存儲能力（t） Powder storage capacity |
100×2 | 100×3 | 100×4 | 200×4 | 200×4 | 300×4 | |
|
螺旋輸送機能力（t/h） Screw conveyor capacity |
55 | 70 | 80 | 110 | 110 | 150 | |
|
水泥計量范圍及精度 Cement weighing range & accuracy |
100~600±1% | 200~1000±1% | 200~1200±1% | 200~1600±1% | 200~1600±1% | 200~1200±1% | |
|
粉煤灰及粉狀外加劑范圍及精度 Coal flyash storage system |
50~200±1% | 50~350±1% | 50~500±1% | 50~800±1% | 50~800±1% | 50~800±1% | |
|
水外加劑儲供系統 Water additives storage system |
水計量范圍（kg） Water weighing range |
50~400 | 50~500 | 50~500 | 50~800 | 50~800 | 50~1000 |
|
水計量精度 Water weighing accuracy |
±1% | ||||||
|
液態外加劑量范圍（kg） Liquid additives weighing range |
5~30 | 5~60 | 5~60 | 5~80 | 5~80 | 5~80 | |
|
液態外加劑量精度 Liquid additives weighing accuracy |
±1% | ||||||
